State Cubes and Events

Synchrony starts by turning raw values into explicit states. This keeps the rule for defining an event separate from the operator used to compare events.

v.detect_events() produces local-cell event instances. Each catalog row is one contiguous run at one spatial cell, not an independent regional episode. Use Local events and regional episodes for explicit space-time consolidation and scope-aware period metrics.

State Cube Contract

Every state constructor returns an xarray.Dataset with:

  • state: boolean active/inactive condition.
  • magnitude: distance beyond the threshold.
  • threshold: scalar or broadcast threshold used to define the state.
from cubedynamics import pipe, verbs as v

hot = (
    pipe(tmax_cube)
    | v.threshold_state(
        threshold=35.0,
        direction="above",
        name="hot_state",
    )
).unwrap()

Quantile states use each pixel's distribution or a rolling window:

cold = (
    pipe(tmin_cube)
    | v.quantile_state(
        quantile=0.5,
        direction="below",
        rolling_window=90,
        name="cold_state",
    )
).unwrap()

Binary masks can be normalized with v.binary_state(), and biological response states can be built with v.change_state().

Event Result Contract

Timing and duration synchrony need event identity. v.detect_events() turns contiguous True runs into an EventResult:

events = (
    pipe(hot)
    | v.detect_events(
        state_var="state",
        magnitude_var="magnitude",
        min_duration=2,
        max_gap=1,
    )
).unwrap()

events.dataset
events.catalog

The Dataset contains event variables such as event_active, event_id, event_age, event_duration, event_peak, event_mean, event_integral, sequence_index, and time_since_previous_event.

The catalog is a pandas DataFrame with one row per event. It stays outside xarray attrs so large event tables remain visible and inspectable.

start and end are the coordinate labels of the first and last active observations. They are not the physical start and end of those observations' support intervals. v.timing_synchrony(event_anchor="start") compares event start labels; event_anchor="end" compares event end labels. This event-time question is separate from verifying that the source observations cover the same hours. See Temporal alignment.

Observational example

The real PRISM states-and-events vignette shows the complete value → state → persistent event → occurrence synchrony story with a declared source, threshold, units, and plotted results. Matched timing and duration diagnostics will be added when a vetted event catalog is available for the publication examples.
